10GBASE-ER 1270nm DFB RX1330nm 10G SFP Module Bi-Directional SM SFP+ 60KM
| Supports 9.95 to 11.3Gb/s bit rates |
| Hot-Pluggable |
| Simplex LC connector |
| 1270nm DFB transmitter, 1330nm PIN-TIA |
| SMF links up to 60km |
| 2-wire interface for management specifications compliant with SFF 8472 digital diagnostic monitoring interface |
| Power Supply :+3.3V |
| Power consumption<1.5W |
| Temperature Range: 0~ 70°C |
Applications
10GBASE-LR/LW
CPRI rates 6.144Gb/s, 9.83Gb/s
10Gb/s Fiber Channel
PRODUCT DESCRIPTION
SFP-10G is a very compact 10Gb/s optical transceiver module for
serial optical communication applications at 10Gb/s. The SFP-10G
converts a 10Gb/s serial electrical data stream to 10Gb/s optical
output signal and a 10Gb/s optical input signal to 10Gb/s serial
electrical data streams. The high speed 10Gb/s electrical interface
is fully compliant with SFI specification.
SFP+10G modules Complaint with IEEE 802.3ae 10GBASE-LR,Electrical interface compliant to SFF-8431 specifications for enhanced 8.5 and 10 Gigabit SFP module “SFP+”,1270nm DFB transmitter, PIN photo-detector,LC connector,2-wire interface for management specifications compliant with SFF 8472 digital diagnostic, Compliant with SFF8472 Digital Diagnostic Standard(DDM)
The SFP+ module electrical interface is compliant to SFI electrical specifications. The transmitter input and receiver output impedance is 100 Ohms differential. Data lines are internally AC coupled. The module provides differential termination and reduce differential to common mode conversion for quality signal termination and low EMI. SFI typically operates over 200 mm of improved FR4 material or up to about 150mmof standard FR4 with one connector.
The high performance 1270nm DFB transmitter and high sensitivity
PIN receiver provide superior performance for Ethernet applications
at up to 60km links.
Optical Characteristics (TOP=25°C, Vcc=3.3 Volts)
| Parameter | Symbol | Min | Typ | Max | Unit | Ref. |
| Transmitter | ||||||
| Output Opt. Power | PO | 0 | 5 | dBm | ||
| Side-Mode Suppression Ratio | SMSR | 30 | dB | |||
| RMS Spectral Width(-20dB) | σ | 1 | nm | |||
| Optical Extinction Ratio | ER | 3.5 | 4.5 | dB | ||
| Tx Jitter(SONET)20KHZ-80MHZ | Txj1 | 0.3 | UI | 3 | ||
| Tx Jitter(SONET)4MHZ-80MHZ | TXj2 | 0.1 | UI | 3 | ||
| Path penalty at 800ps/nm@9.95Gb/s | 2 | dB | ||||
| Relative Intensity Noise | RIN | -128 | dB/Hz | |||
| Center Wavelength | λc | 1260 | 1270 | 1330 | nm | |
| Receiver | ||||||
| RX Sensitivity @10.3 Gb/s | SENS | -16 | dBm | 1,2 | ||
| Receiver Overload | -1 | dBm | ||||
| Optical Center Wavelength | λC | 1320 | 1330 | 1340 | nm | |
| LOS De-Assert | LOSD | -18 | dBm | |||
| LOS Assert | LOSA | -30 | dBm | |||
| LOS Hysteresis | 0.5 | dB | ||||
Notes:
1. Measured with conformance signals defined in FC-PI-2 Rev. 10.0 specifications.
2. Measured with PRBS 231-1 at 10-12 BER.
3. GR-253-CORE Issue 4.
4. With optical input power at the receiver between -1 ~ -11dBm
Recommended Operating Conditions
| Parameter | Symbol | Unit | Min | Typ | Max |
| Storage Temperature Range | Ts | ℃ | 0 | 70 | |
| Power Supply Voltage | Vcc | V | 3.135 | 3.3 | 3.465 |
| Data Rate | Gb/s | - | 10 | - |
|
|
