155BASE 60KM SFP Single Mode Fiber Module LC Connector TX1550nm

PRODUCT DESCRIPTION

This module is designed to be compliant with SFF-8472 SFP Multi-source Agreement (MSA)

60KM Duplex LC Single Mode 155Mb/S Optical Transceiver Module Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA), The transceiver consists of four sections: the LD driver, the limiting amplifier, the 1550nm DFB laser and the PIN photo-detector. The module data link up to 60KM in 9/125um single mode fiber.

The transmitter section uses a multiple quantum well laser and is a class 1 laser compliant according to International Safety Standard IEC-60825. The receiver section uses an integrated InGaAs detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.

PRODUCT FEATURES

Compliant with MSA SFP Specification

Distance up to 60KM

Hot Pluggable,Metal enclosure, for Lower EMI

DDM function optional

Digital Diagnostic Monitor Function Compatible with SFF-8472

Single 3. 3V Power supply

Operating data rate up to 155Mbps

Tx1550, 1550nm DFB Laser, PIN-TIA

Dual LC Connector Interface

Operating Case Temperature: Commerical:0 to 70 °C Industrial:-40 to 85 °C

2 years warranty

Applications:

-- Fast Ethernet
-- Metro/Access Networks
--100Base-LX Ethernet
--SONET OC-3/SDH STM-1

Specification of Receiver

Note (1): Measured with Light source 1550nm, ER=8.2dB; BER =<10^-12 @PRBS=2^23-1 NRZ

Note (2): When LOS de-asserted, the RX data+/- output is High-level (fixed)

Specification of Transmitter

Note (1): Measure at 2^23-1 NRZ PRBS pattern

Note (2): Transmitter eye mask definition
